Single Packaged Gas/Electric Air Conditioner 16 SEER, Single-Phase, 5 Ton, 81% AFUE, R410A, Multi-Position

Single Packaged Gas/Electric Air Conditioner 16 SEER, Single-Phase, 5 Ton, 81% AFUE, R410A, Multi-Position

SEER: 16; EER: 12.0; Nom. Tons: 5; BtuH Cooling: 58,000; BtuH Heating Input: 138,000; BtuH Heating Output: 112,000; Volts: 208/230; Phase: Single; Motor Type: ECM; Nom. CFM: 2,000; Min. Circuit Amps: 43.4; Refrigerant: R-410A; Width: 48-49/250"; Height: 42-21/25"; Depth: 73-189/200"; Wt. Lbs.: 655;

Order #: B63-644

Internal Product ID:

Mfg. #: GPG1660140M41

Brand: Goodman

Box Qty:

Product Specifications
BtuH Cooling 58,000
BtuH Heating Input 138000
BtuH Heating Output 112,000
Depth 73-189/200"
EER 12.0
Height 42-21/25"
Min. Circuit Amps 43.4
Motor Type ECM
Nom. CFM 2,000
Nom. Tons 5
Phase Single
Refrigerant R-410A
SEER 16
Volts 208/230
Width 48-49/250"
Wt. Lbs. 655
Shipping Weight 630.00
Shipping Width 48.31
Shipping Length 74.00
Shipping Height 43.50
Compliance/Notes
Harmonize Code 8415.82.0115
Country of Origin UNITED STATES

Contact your local store for additional notes and/or restrictions

Description
  • High-efficiency compressor
  • Copper tube/aluminum fin coil
  • Aluminum-copper evaporator coil
  • Multi-speed ECM blower motor
  • T-140 aluminized steel tubular heat exchanger
  • Power-assisted combustion
  • Direct spark ignition system with microprocessor based control
  • Self-diagnostic blower operation and safety circuits
  • Loss-of-charge protection & high-pressure switch Two-stage gas valve
  • Easy conversion to propane
  • Fully insulated cabinet
  • Horizontal or downflow application
  • California LoNOx approved
  • 208/230V
