Single Packaged Heat Pump 16 SEER, Single-Phase, 5 Ton, R410A, Multi-Position

Single Packaged Heat Pump 16 SEER, Single-Phase, 5 Ton, R410A, Multi-Position

SEER: 16; EER: 12.0; Nom. Tons: 5; BtuH Cooling: 58,000; BtuH Heating Input: 58,000; Volts: 208/230; Phase: Single; Motor Type: ECM; HSPF: 8.2; COP: 3.7; Nom. CFM: 1,800; Min. Circuit Amps: 44.0; Refrigerant: R-410A; Width: 48-49/250"; Height: 42-21/25"; Depth: 73-189/200"; Wt. Lbs.: 688;

Order #: B63-645

Internal Product ID:

Mfg. #: GPH1660M41

Brand: Goodman

Box Qty:

Product Specifications
BtuH Cooling 58,000
BtuH Heating Input 58000
COP 3.7
Depth 73-189/200"
EER 12.0
HSPF 8.2
Height 42-21/25"
Min. Circuit Amps 44.0
Motor Type ECM
Nom. CFM 1,800
Nom. Tons 5
Phase Single
Refrigerant R-410A
SEER 16
Volts 208/230
Width 48-49/250"
Wt. Lbs. 688
Shipping Weight 612.00
Shipping Width 48.31
Shipping Length 74.00
Shipping Height 43.50
Compliance/Notes
Harmonize Code 8415.82.0115
Country of Origin UNITED STATES

Contact your local store for additional notes and/or restrictions

Description
  • 2-stage compressor with internal relief valve
  • 2-stage heating and cooling
  • Multi-speed ECM blower motor
  • Liquid-line filter-drier
  • Convertible airflow horizontal or downflow
  • Copper tube/aluminum fin condenser coils
  • Fully insulated air-handling compartment
  • Louvered condenser coil protection
  • HKP/R heat kits sold separately
  • 208/230V
