SEER: 20.9; SEER Non-Ducted: 20.9; SEER Ducted: 17.8; EER Non-Ducted: 11; EER Ducted: 11.1; HSPF Non-Ducted: 9.3; HSPF Ducted: 10.3; BtuH Cooling: 9,000; Min. Cooling Capacity BtuH: 3,900; Max. Cooling Capacity BtuH: 10,700; BtuH Heating: 10,900; Min. Heating Capacity BtuH: 3,900; Max. Heating Capacity BtuH: 14,000; CFM High: 985; Volts: 208/230; Amps Cooling: 9; Max. Fuse Size: 15; Cooling Temperature Range Deg.F: 50 - 115; Heating Temperature Range Deg.F: 5 - 65; Sound Pressure Cooling dBA: 46; Sound Pressure Heating dBA: 50; Liquid Conn.: 1/4"; Suction Fitting: 3/8"; Min. Total Pipe Length: 5; Max. Total Pipe Length: 65; Min. Each Pipe Length: 5; Max. Each Pipe Length: 65; Refrigerant: R-410A; Width: 26-9/16"; Height: 21-5/8"; Depth: 11-3/16"; Wt. Lbs.: 60; Min. # of Connectable Indoor Units: 1; Max. # of Connectable Indoor Units: 1; Min. Connectable Capacity: 9,000; Max. Connectable Capacity: 9,000; Nom. Capacity: 9,000;
Order #: B65-645
Internal Product ID:
Mfg. #: RX09RMVJU9A
Brand: Daikin
Box Qty:
| Amps Cooling | 9 |
|---|---|
| BtuH Cooling | 9,000 |
| BtuH Heating | 10,900 |
| CFM High | 985 |
| Cooling Temperature Range °F | 50 - 115 |
| Depth | 11-3/16" |
| EER Ducted | 11.1 |
| EER Non-Ducted | 11 |
| HSPF Ducted | 10.3 |
| HSPF Non-Ducted | 9.3 |
| Heating Temperature Range °F | 5 - 65 |
| Height | 21-5/8" |
| Liquid Conn. | 1/4" |
| Max. # of Connectable Indoor Units | 1 |
| Max. Connectable Capacity | 9,000 |
| Max. Cooling Capacity BtuH | 10,700 |
| Max. Each Pipe Length | 65.00 |
| Max. Fuse Size | 15 |
| Max. Heating Capacity BtuH | 14,000 |
| Max. Total Pipe Length | 65.00 |
| Min. # of Connectable Indoor Units | 1 |
| Min. Connectable Capacity | 9,000 |
| Min. Cooling Capacity BtuH | 3,900 |
| Min. Each Pipe Length | 5.00 |
| Min. Heating Capacity BtuH | 3,900 |
| Min. Total Pipe Length | 5.00 |
| Nom. Capacity | 9,000 |
| Refrigerant | R-410A |
| SEER | 20.9 |
| SEER Ducted | 17.8 |
| SEER Non-Ducted | 20.9 |
| Sound Pressure Cooling dBA | 46 |
| Sound Pressure Heating dBA | 50 |
| Suction Fitting | 3/8" |
| System # | 09RMVJU9A |
| System Flex | Y |
| Unit Type | Outdoor |
| Volts | 208/230 |
| Width | 26-9/16" |
| Wt. Lbs. | 60 |
| Zone Type | Single-Zone |
| Shipping Weight | 60.00 |
| Shipping Width | 26.56 |
| Shipping Length | 11.19 |
| Shipping Height | 21.63 |
| Harmonize Code | 8415.90.8065 |
|---|---|
| Note | *For complete specifications and match-ups go to the Mini-Split Selector |
| Country of Origin | THAILAND |
Contact your local store for additional notes and/or restrictions
WARRANTY - Johnstone Supply will administer and promptly process all warranties in accordance with the manufacturer's specific warranty policies and procedures.
WHOLESALE ONLY - Identification is required of purchasers. Possession of Johnstone's catalog does not constitute an offer to sell by Johnstone or the right to purchase from us.
RETURNS - All returns are subject to a restocking charge.
